4 Post
  • Product Introduction
  • Specification
Model SLD-T38
Lifting Capacity 3500/4000/5000kg
Lock Release System Manual unlock (standard)
Lifting Height 1500mm
Secondary Lifting Height 450mm
Minimum Height 200mm
Platform Length 4500/4500/5000mm
Platform width 550mm
Overall Length 4880/4880/5380mm
Overall Width 3260mm
Width Between Pillars 2900mm
Width Between Runway 860/860/900mm
Post Height 2000mm
Lifting/Falling Time 50s/60s
Motor Power 2.2KW
Power Voltage 380V/220V
Self-Weight 1200/1200/1400KG
Outline Dimension 4880/4880/5380*3260*2020mm
Package Dimension 4700/4700/5500*600*800mm
  • Features
1. Hydraulic drive , steel rope lifting system
2. Adjustable self-lock system ensure the vehicle safe in different height , pneumatic lock release, steel rope anti-dropping device
3. Self-lubricating bearing to ensure the safety
4. Four points automatic safety locks
5. Heavy duty sliding turnplate
6. Slideway inside of the runway for other equipments
7. Anti-falling blocks in all the posts to add safety
8. Free caster kit for moving the lift ,Diamond plate runways and ramps
9. Hydraulic middle rolling jack , manual or pneumatic
10. Polished and powder coated posts.
