Specification |
|
Model |
OBC-C400 |
OBC-C400D |
|
Material |
Manganese steel |
Manganese steel |
|
Platform length |
5600/5900/6700mm |
5600/5900/6700mm |
|
Platform width |
2200mm |
2200mm |
|
Max platform height |
550mm |
550mm |
|
Up-and-down |
Single side tilting platform |
Single side tilting platform |
|
Steel plate thickness |
10mm |
10mm |
|
Platform thickness |
124mm |
124mm |
|
Air pressure required |
0.6-0.8Mpa |
0.6-0.8Mpa |
|
Hydraulic Power |
70MPa (10000psi) |
70MPa (10000psi) |
|
Max.pulling capacity |
98KN(10 tons) |
98KN(10 tons) |
|
Max.lifting capacity |
3500kgs |
3500kgs |
|
